Electromagnetic flow meter Manufacturer in Mumbai India
A device called an Electromagnetic flow meter detects the flow of conductive liquids. This flow meter really measures volume. Additionally, it can test different fluid types that are used in a variety of industrial operations. The sewage treatment plant, water supply plants, effluent treatment plants, pulp and paper, distilleries, sugar and steel industries, as well as the chemical, culinary, and pharmaceutical industries, are among the industries where this magnetic flow meter is used.
This mag flow meter, also known as a magnetic flow meter, gauges liquid flow and operates according to Faraday’s law of electromagnetic induction. According to Faraday’s law, “in an electrically conducting body moving in a magnetic field, voltage is induced, and this voltage is directly proportional to the velocity.” This gadget has a PTFE lining and no moving components.
The measurement of flow via a flow meter is unaffected by pressure, density, viscosity, dissolved or undissolved particulates,
The measurement of flow via a flow meter is unaffected by pressure, density, viscosity, dissolved or undissolved particulates, or temperature until the moving liquid maintains a certain minimum conductivity. The common outputs for electromagnetic flow meters include analog, frequency, RS 232/RS 485 connection, or GSM connectivity. Local and remote display models with weatherproof and flameproof enclosures are available from us as an optional feature.
Specifications
Flange Sizes: 150# ANSI: 15mm to 300 mm (0.5” to 12”)
Maximum Pressure: 10 kg/cm 2Minimum
Display: Digital
Conductivity: 10 uS
Output: 4-20mAdc or Modbus RTU
Electrode Material: SS316, others optional
Environmental Temperature: -5 to 55 C (23 to 131oF)
Graphical LCD, Velocity Display Liquid Temperature: 0 to 150oC (32 to 302oF)
Accuracy: +/-1% of span
Application Media: Water, Any conductive Liquid
Flow Range: 0.3 to 10 m/s
Power Supply: 230 VAC
Frequency: 0 to 1000 Hz
With galvanic isolation
Protection: IP67
Electronics Enclosure: IP67
Applications
Automobile Industries: Flow measurement of coolant, for radiator efficiency.
Boiler: Feed Water Measurement.
Chemical Industries: Measurement of acidic, alkaline chemicals, and slurries with & without dissolved solids.
Effluent Treatment: Untreated as well as treated effluent measurement.
Food & Beverages: Special end connections like SMS union, tri-clover clamp, fully SS body, PTFE, or PFA liner are available.
Industrial Utility Management: Measuring water consumed by each plant, Water audit, Measurement of Spent wash, Fermented wash molasses, etc.
Sewage Treatment: Wastewater measurement, Sludge measurement, etc.
Sugar Industries & Distilleries: Measurement of imbibition water, raw juice, etc.
Water Supply Schemes: Raw water as well as treated water measurement.
Advantages
Wide range of sizing DN 25 to DN 350
End Connection: Flange type available in various standards viz. ANSI, DIN, BS etc.
Unaffected by the temperature, pressure, density, or viscosity of the liquid.
Able to detect liquids that include contaminants (solids, air bubbles)
There is no pressure loss.
No moving parts (improves reliability)
Disadvantages
Cannot detect gases and liquids without electrical conductivity.
